Utility scale liquid cooling solution
| Model | SU344C170K/SU344C340K |
| Max Power | 172KW/344KW |
| Nameplate Capacity | 344.06kWh |
| Cell Chemistry & Format | LFP(LiFePO4),16S1P |
| Battery Chemistry | LFP |
| Copocity | 280Ah |
| Configuration | 384S1P |
| Nominal Voltoge | 1228.8V |
| Voltage Range | 1075.2~1382.4V |
| Degree of Protectio | NEMA 3R / IP54 |
| Noise Emission | ≤65dB@1m |
| Operating Temperature Range | -22°F~113°F/-30℃~50℃ |
| Relative Humidity | 0~95%(No condensin) |
| Max Working Altitude | 6,500ft/ 2,000m |
| Dimensions(W*H*D) | 1300×2335×1400mm |
| Weight | 3500kg |
| Cooling | HVAC |
| Cooling Method of Battery Chamber | Liquid Cooling |
| Fire Suppression System | Aerosol |
| Certificate | UL1973,UL9540A,IEC62619,IEC61000 |
