Model AK-AH01
Cell Chemistry & Format LFP(LiFePO₄),16S1P
Nominal Capacity 100Ah
Battery Usable Energy 5.12kWh
Nominal Valtage 51.2V
Nominal Output Current 100A
BMS Protection Current 120A,1s
Charge Voltage 57.6V
Charge Current 30A
Max Charge Current 50A
Peak Charge Current 100A
Charging Mode Constant Current/Constant Voltage
Discharge Cut-Off Voltage 41.6V
Discharge Current 50A
Max Discharge Current 100A
Nominal Output Power 5KW
Nominal Qutput Voltage 230Vac
Display SOC status indicator,LED indicator
Communication CANIRS485/RS232
Dimension(L*W*H) SIZE①:650*252*402Hmm,SIZE②:650*252*400Hmm
Weight 85KG
Charge Temperature 0 to 55℃ (32 to 131°F)
Operatingemperature -20 to 75℃ (-4 to 167°F)
Storage Temperature -20 to 45℃ (-4 to113°F)
nvironmental Humidity 0-95%RH (No condensation)
Cycle Life ≥5000 Cycles@80%DOD/25℃/0.5C,60%EOL
Scalability Max 1 batteries in parallel
