Model | AK-EH05 | AK-EH06 |
Inverter Type | 5.5KW/51.2V AC hybrid inverter | |
Rated Output Power | 5.5KW | |
Normal Battery Modular | 51.2V100Ah*3 | 51.2V100Ah*4 |
Normal Capacity(25℃,0.2C) | 15.36KWH | 20.48KWH |
Nominal Battery Voltage | 51.2Vdc | |
Output Voltage Waveform | Pure Sine Wave | |
Output Voltage | 230VAC 50HZ | |
Low DC Warning Voltage | 44.8Vdc | |
Low DC Cut-off Voltage | 43.2Vdc | |
Low DC Warning Return Voltage | 44.8Vdc | |
Total Charging Current(Grid+solar) | 100A Max | |
Bulk Charging Voltage | 58.6Vdc | |
Float Charging Voltage | 57.6Vdc | |
Product dimensions | 598*445*813mm | 598*445*1021mm |
